Side-entry lifting lugs (left- and right-hand) inserted into the bottom corner casting side aperture for safe container lifting; SWL 12.5 tons per lug; certified lifting equipment — use in sets of 4.
No prices online — quotations are prepared per application and quantity, usually within one business day; a more involved enquiry may take a little longer.
| Material | Cast steel |
|---|---|
| Load Rating (SWL) | 12.5 tons per lug |
| Weight | 4 kg per lug; lifting hole diameter 70 mm |
| Finish / Coating | Powder-coated yellow |
| Lateral variant | Type-approved lateral lifting lug — SWL 10 t at 36° sling angle / 8 t at 50° (DNV type approval TAS00003Y2) |
Load ratings are as published in the TLA 2026 catalogue. Site-specific ratings and certification: on request.
Container lifting with cranes using bottom corner castings; set of 4 (2 LH + 2 RH) required; shackle required to connect to lashing equipment.
A well-established industry-standard fitting that inserts into the side hole of the bottom corner casting — two left-hand and two right-hand lugs per set, pointed towards each other when correctly installed. As certified lifting equipment it must not be dropped on hard surfaces and should be used only for its intended container-lifting purpose; a shackle connects it to the lashing or lifting equipment above. A second, lateral lifting lug variant carries independent third-party type approval rating it to 10 t SWL at a 36° sling angle or 8 t at 50°.
⬇ Download the datasheet (PDF · draft A)
◇ Technical drawing — included in the datasheet above.
⛭ Available for hire — rates on application.
Container corner jack for levelling or full-container lifting; used with a 10-ton hydraulic jack, lifting each corner up to a maximum of 250 mm. A minimum of two is recommended, used as a pair to lift two adjacent corners.
Corner jack with integrated locking trestle rod; raises container corners ~200 mm and locks at height so the hydraulic jack can be removed; trestle rod SWL 4 tons per jack.
ConFoot CFU 20 — four self-contained hydraulic-jack legs lift a container off any trailer or chassis and lower it to the ground in 5–10 minutes, no crane or forklift required; 20-tonne set capacity; frees the truck to leave immediately.
Top-entry lifting lugs for crane lifting via top corner castings; safety slider prevents accidental removal in use; SWL 56 tons for a set of 4; certified lifting equipment — use in pairs of 2 or 4.
