Mounting-face detail of the Domino Clamp — the four M12 tapped holes and clamp jaw that engage the corner casting's shield or stadium hole, including when a twistlock is already occupying the corner.
No prices online — quotations are prepared per application and quantity, usually within one business day; a more involved enquiry may take a little longer.
| Working Load — Shield Hole | 1100–2000 kg, direction-dependent (OEM data) |
|---|---|
| Working Load — Stadium Hole | 1100–2000 kg, direction-dependent (OEM data) |
| Coexistence | Can be used in the shield and/or stadium holes even when a twistlock already occupies the corner casting |
Load ratings are as published in the TLA 2026 catalogue. Site-specific ratings and certification: on request.
Scaffolding and tube clamp structures; engineered steel and timber structures bolted directly to the clamp; 42 mm tube mounts for Heras-type fencing; lighting conductors and cladding rails.
The clamp jaw locates in the corner casting's shield hole or stadium hole — not the top hole — and can occupy both simultaneously for a stronger multi-point fixing, even when a twistlock is already engaged in the same corner. OEM working-load data rates each hole at 1100–2000 kg depending on load direction. The four M12 tapped holes on the mounting face accept bolts directly, letting engineered steel or timber structures, tube-clamp scaffolding, or fencing bolt straight to the container corner.
⬇ Download the datasheet (PDF)
◫ 3D model (STEP) — Available on request (WhatsApp)
◇ Technical drawing — included in the datasheet above.
